FHPR34-HP1 Aquafilter pipe housing for 10bar 3/4"

Reinforced inline housing for cold water systems

Aquafilter FHPR34-HP1 is a 10-inch, two-piece inline housing designed for installation on the cold water supply line. The design consists of two basic elements: a transparent sump and a head with a 3/4" brass thread. This construction combines ease of use with high resistance to everyday operation in domestic and utility water draw-off points.

This is a reinforced version, adapted to continuous operating pressure up to 10 bar. Thanks to this, the housing performs well wherever durability, stable operation, and filtration system tightness are required.

Design that makes everyday use easier

The transparent sump allows you to quickly assess the degree of cartridge contamination without having to dismantle the entire set. This is a practical solution that helps better plan filter cartridge replacement and maintain high filtration efficiency.

The FHPR34-HP1 model is equipped with two sealing O-rings: one face seal and one under the head. The double sealing increases connection tightness and improves the safety of housing operation at higher pressure.

An additional convenience is the pressure relief valve, which allows the release of air collected in the filter after cartridge replacement. This makes restarting the system easier and reduces problems related to the presence of air bubbles in the housing.

Use at home and for appliance protection

The housing can be installed individually or connected in series with other housings to create a more advanced water filtration system. This flexibility makes it possible to adapt the installation to user needs and the type of cartridges used.

FHPR34-HP1 is installed on the pipe supplying cold water to the apartment, especially where there is moderate water demand. The housing can also be installed before household appliances such as a washing machine or dishwasher, helping protect them against the buildup of various types of contaminants present in water.

Thanks to compatibility with a wide range of 10" cartridges, the housing can perform different functions depending on the filtration medium used. It is a good choice both for preliminary mechanical filtration and for more specialized stages of water treatment.

Compatibility with 10-inch cartridges

The housing works with a wide range of 10-inch cartridges available on the market. The following cartridges can be used:

• mechanical,
• specialist,
• carbon,
• softening,
• iron removal,
• antibacterial.

Thanks to this, one housing can serve as a universal base for various filtration configurations, from basic installation protection to more advanced systems preparing water for further purification stages.

Installation and important operating notes

The housing should be properly mounted to maintain operational stability and connection tightness. For correct installation, the housing should be suspended on a mounting plate.

Package contents

The set includes all the components listed below:

• FHPR34-HP1 inline housing
• Two sealing O-rings
• FCPS5 polypropylene foam filter cartridge
• Bacteriostatic centering disc
• Wrench
• Mounting plate

Main product advantages

• reinforced construction for continuous operating pressure up to 10 bar,
• two-piece housing: transparent sump and head with 3/4" brass thread,
• two sealing O-rings improving tightness,
• pressure relief valve facilitating startup after cartridge replacement,
• can be installed individually or in series,
• application on the cold water supply line and before household appliances,
• supports a wide range of 10" cartridges for various filtration applications.
