Big Blue 20-inch cartridges
FCPS1M20B Aquafilter 1 micron BIG BLUE 20" cartridge
Rating
FCPS1M20B Aquafilter is a pink polypropylene sediment filter with a precision of 1 micron, designed for BIG BLUE 20" housings. It filte Read moreShow less
FCPS1M20B Aquafilter is a pink polypropylene sediment filter with a precision of 1 micron, designed for BIG BLUE 20" housings. It filters through the entire structure of the cartridge, effectively trapping mechanical impurities such as sand, silt, sludge, and rust. For cold water filtration. It has NSF certification and a PZH approval.
Benefits
- Captures sand, sediment and rust particles
- Protects subsequent filtration stages
Specifications
FCPS1M20B
In stock
- Temperatura pracy
- 2°C - 45°C
- Żywotność
- do 6 miesięcy*
- Wydajność
- do 60 l/min
- Spadek ciśnienia
- 0,3 - 0,5 bar
- Cartridge diameter
- 4,5″
- Cartridge length
- 20″
View full specifications
- Cartridge type
- Foam sediment, Sediment
- Compatibility
- Big Blue 20"
- Filtration rating
- 1 µm
- Housing standard
- Big Blue 20″
- Material
- Polypropylene
- Filter media
- Polypropylene
- Model
- FCPS1M20B
- Product type
- Filter cartridge
- Reusable
- No
Description
FCPS1M20B Aquafilter is an efficient sediment filter cartridge with 1-micron filtration for BIG BLUE 20" housings, designed for effective cold water filtration. As a mechanical water filter, it captures fine solid contaminants such as sand, silt, sludge, rust, and suspended solids, supporting everyday water treatment in residential and commercial installations. The polypropylene nonwoven construction filters through the entire cartridge volume, combining high purification efficiency with low pressure drop.
Effective mechanical filtration in BIG BLUE 20" housings
Aquafilter FCPS1M20B is a foam sediment cartridge made of polypropylene nonwoven fabric. It is designed for use with 20" Big Blue housings and performs well wherever mechanical contaminants need to be removed from water before further use.
The 1-micron filtration rating effectively reduces the presence of fine solid particles, helping to protect the water system and devices operating as part of a broader water filtration system.
What contaminants does the FCPS1M20B cartridge remove?
The cartridge cleans water of fine solid contaminants and mechanical sediment. It is designed to retain, among others, contaminants such as:
- sand,
- sludge,
- silt,
- rust,
- suspended solids.
This is a practical solution as a preliminary filtration stage in residential and commercial installations, also where protection of subsequent elements such as a finer filter cartridge, a reverse osmosis filter, an osmotic filter, or a complete reverse osmosis system is important.
Filtration through the entire cartridge structure
The way the polypropylene nonwoven fabric is formed means that water is filtered through the entire cartridge structure, not only on its surface. This design promotes even retention of contaminants and supports stable cartridge performance during everyday use.
In practice, this means a combination of effective separation of mechanical contaminants while maintaining low pressure drop, which is of great importance in installations supplying a water outlet point or an extensive water filtration system.
Key advantages of the cartridge
- Removes mechanical contaminants (rust, sand, silt, suspended solids).
- Provides excellent filtration with low pressure drop.
- Has PZH approval.
- Manufactured in the EU.
Application
The FCPS1M20B model is intended for cold water filtration. It can be used as a pre-filtration element in water installations wherever the goal is to reduce the amount of sediment and solid particles present in the water.
Thanks to compatibility with BIG BLUE 20" housings, the cartridge is used in residential and commercial solutions where effective protection of fittings, devices, and subsequent treatment stages matters.
The cartridge is intended for use with cold water. Cartridge service life depends on water quality and the amount of retained contaminants, so replacement frequency should be adjusted to actual operating conditions.
Quality and safety of use
The cartridge has NSF certification and PZH approval, confirming its suitability for water filtration applications. An additional advantage is manufacturing within the EU.
Technical specifications
| Model | FCPS1M20B |
|---|---|
| Brand | Aquafilter |
| Product type | Sediment cartridge (foam) |
| Material | Polypropylene nonwoven fabric |
| Filtration rating | 1 micron |
| Compatibility | BIG BLUE 20" housings |
| Intended use | Filtration of mechanical contaminants |
| Removed contaminants | Sand, sludge, silt, rust, suspended solids |
| Application range | Cold water |
| Filtration method | Filtration through the entire cartridge structure |
| Certificates and approvals | NSF, PZH approval |
| Place of manufacture | EU |
Questions
Which housings is the FCPS1M20B cartridge compatible with?
The cartridge is designed for use with 20" BIG BLUE housings.
What is the filtration rating of this cartridge?
The FCPS1M20B model offers a 1-micron filtration rating, effectively retaining fine mechanical contaminants present in water.
What contaminants does this sediment cartridge remove?
The cartridge removes mechanical contaminants, including rust, sand, silt, sludge, and suspended solids.
Is the cartridge suitable for cold or hot water filtration?
The product is intended for cold water filtration.
What material is the cartridge made of?
The cartridge is made of polypropylene nonwoven fabric formed in a way that enables filtration through the entire material structure.
What are the main advantages of filtration through the entire cartridge structure?
This design supports effective retention of mechanical contaminants and allows excellent filtration to be maintained with low pressure drop.
Does the cartridge have the required approvals and certifications?
Yes, the cartridge has NSF certification and PZH approval.
How often should the cartridge be replaced?
Cartridge service life depends on water quality and the amount of mechanical contaminants, so the replacement interval should be adjusted to actual usage conditions.
Can this cartridge work as a preliminary stage before finer filtration?
Yes, the sediment cartridge works very well as a preliminary stage for protecting the installation and subsequent water treatment elements, such as finer cartridges or membrane systems.
