The automatic anti-flood valve 1" protects water installations from leaks thanks to a wireless sensor, a ceramic valve, and a built-in …Read moreShow less
The automatic anti-flood valve 1" protects water installations from leaks thanks to a wireless sensor, a ceramic valve, and a built-in battery.
Automatic Anti-Flooding System Water Shut-Off Valve 1" is a practical protection for water installations against the effects of leaks. The system automatically shuts off the water supply after flooding is detected by a wireless sensor, helping protect homes, service premises, offices, and technical facilities from costly damage. This solution complements a modern water installation well, devices such as a water filter, water treatment systems, and an advanced water filtration system, wherever safety and a quick response to leaks matter.
Notable features include a ceramic ball valve with low torque, wireless communication with the sensor, energy-efficient operation, and a built-in lithium battery for emergency use. The set has been designed for convenient operation and reliable water shut-off when liquid is detected.
Effective protection against flooding of the installation
Water installation components are exposed to leaks, especially with excessively high pressure, worn connections, or installation errors. Even a minor leak can quickly lead to significant material losses and damage to floors, walls, furniture, or technical equipment.
The 1" automatic anti-flooding valve has been designed as active protection against such situations. After the sensor detects water, the system immediately shuts off the supply, reducing the risk of spreading water and further damage.
How the 1" anti-flooding system works
The system consists of an automatic ceramic valve and a wireless flood sensor. The sensor should be placed where water most often appears in the event of a failure, for example near a washing machine, dishwasher, under the sink, near a tank, water treatment station, or within the water distribution area.
When water appears between the sensor probes, an electric current is generated, which triggers the ball valve to close. The water supply is cut off automatically, without the need for manual intervention by the user.
The ceramic valve head with a small flow opening reduces the force needed for the working movement. As a result, the valve operates efficiently and energy consumption remains low, which is especially important during operation without external power.
Main features and benefits
Wireless flood sensor – sends wireless signals and allows operation of up to 5 sensors simultaneously. The set includes 1 sensor.
Low energy consumption – the device is energy-efficient and allows easy battery replacement.
Ceramic ball valve – the ceramic core with low torque ensures minimal flow resistance and a small water pressure drop.
Built-in lithium battery – the control valve has a high-capacity lithium battery that can be used in emergency situations.
Waterproof sensor design – the flood sensor is water-resistant, helping protect internal circuits against corrosion.
Leak protection – the system effectively prevents leaks in various types of installations.
Easy installation – simple mounting without the need for complicated plumbing work.
Reliability – high-quality materials and advanced technology support long-term operation.
Energy efficiency – low power consumption and battery operation in emergency situations.
Versatility – a solution suitable for domestic, commercial, and industrial applications.
System design
The design is based on components responsible for control, flood detection, and reliable water shut-off. The complete system design includes:
Dust cover for the control valve
Main valve control board
Rechargeable lithium battery
Ceramic core valve
Stainless steel electrode
Flood sensor control unit
Alkaline battery
Top cover of the flood sensor
Application
The system can be used in domestic, commercial, and industrial installations. It works wherever a water leak can cause costly downtime or damage to equipment.
in houses and apartments,
in service premises and offices,
in technical rooms,
with household appliances that use water,
at points where a water filter or water filtration system is operating,
with systems responsible for water treatment.
The flood sensor should be mounted at the lowest point of the area exposed to leaks, where water will appear first. Correct sensor placement has a direct impact on the response speed of the entire system.
Dimensions and mounting fit
The 1" model has been prepared for use in installations requiring a solid, secure connection and a compact layout. Detailed dimensions make it easier to plan the installation location and cable routing.
Length: 130 mm
Length 1: 51 mm
Length 2: 109 mm
Length 3: 84 mm
Length 4: 104 mm
Height: 110.2 mm
Width: 36 mm
NPS: G1
Operation and practical use
The automatic anti-flooding system has been designed for everyday operation in water installations. Thanks to low energy consumption and the option of emergency power from the built-in battery, it supports installation safety even when continuity of operation matters.
The device allows expansion of the detection system to up to 5 sensors, making it easier to secure several zones at once. This is especially useful in larger apartments, houses, service premises, and technical facilities.
To maintain full effectiveness, it is worth periodically checking the sensor battery condition, the correctness of wireless communication, and the free movement of the valve. Regular inspection of the installation site helps keep the system ready for operation.
Why choose this system
This solution combines automatic water shut-off, energy-efficient operation, and a practical design prepared for everyday use. The ceramic ball valve reduces flow resistance and helps maintain a low pressure drop, while the wireless sensor makes it easy to monitor the area most exposed to flooding.
If you want to increase the safety of your water installation and protect property from the effects of a failure, the 1" automatic anti-flooding valve is a solution that genuinely raises the protection level of the entire system.
Technical specification
Parameter
Value
Product type
Automatic anti-flooding system / water shut-off valve
NPS
G1
Valve type
Ceramic core ball valve
Flood sensor
Wireless
Maximum number of supported sensors
Up to 5
Power input
100-240 VAC
Power output
DC12V
Battery parameters
2500mAh / 7.4V – rechargeable lithium battery
Operating temperature range
5-50°C
Length
130 mm
Length 1
51 mm
Length 2
109 mm
Length 3
84 mm
Length 4
104 mm
Height
110.2 mm
Width
36 mm
Power consumption
Low
Sensor design
Waterproof
Working element material of the valve
Ceramic core
Electrode
Stainless steel
FAQ
How does the automatic anti-flooding valve 1" work?
The system works with a wireless flood sensor. When water is detected between the probes, the sensor sends a signal and the ball valve automatically shuts off the water supply.
Is a flood sensor included in the set?
Yes. The set includes 1 wireless flood sensor.
How many sensors can the system support?
The system supports up to 5 sensors at the same time, allowing several leak-prone zones to be protected.
Does the valve work in emergency situations?
Yes. The control valve is equipped with a built-in high-capacity lithium battery that can be used in emergency situations.
What are the main advantages of the ceramic ball valve?
The low-torque ceramic core ensures low flow resistance, a small pressure drop, and lower energy demand for valve operation.
Where is the best place to mount the flood sensor?
The sensor is best placed where water would appear first during a failure, for example under the sink, near a washing machine, dishwasher, water treatment devices, or near the installation manifold.
What power supply does the system use?
The power input is 100-240 VAC, and the power output is DC12V. In addition, the device uses a 2500mAh / 7.4V lithium battery.
In what temperature range can the device operate?
The operating temperature range is from 5 to 50°C.
Is the Automatic Anti-Flooding System Water Shut-Off Valve 1" only suitable for home use?
No. The system is suitable for domestic, commercial, and industrial applications, wherever a quick response to a water leak is needed.
Wireless flood sensor for the anti-flooding system with a controlled water shut-off valve. Installed in the location where water appears most quickly in the event of a leak. Upon contact of the probes with water, the sensor sends a radio signal, which can trigger the closure of the ball valve and cut off the water supply behind the valve. The waterproof design reduces the risk of corrosion of the electronics.
