FR-550 flow restrictor
FLOW550
190152007320
Rating
FR-550 restrictor (flow limiter) for reverse osmosis systems, mounted on the wastewater outlet. It enforces the proper water flow, which supports the flushing and cleaning of the osmotic membrane and helps to drain contaminants into the sewage system. Connection via quick couplings. When replacing the membrane, it is recommended to install a new restrictor.
Description
FR-550 is a flow restrictor designed for use in reverse osmosis systems. The element is installed on the wastewater outlet, where it enforces the correct water flow in the reverse osmosis filter. This supports membrane flushing, helps remove accumulated contaminants to the sewer, and helps maintain the proper operation of the entire water filtration system. Quick-connect fittings make installation and replacement easier.
Application and role of the FR-550 restrictor
The FR-550 flow restrictor is used in reverse osmosis systems on the wastewater discharge line. It is a small but very important component that affects the operating conditions of the osmosis membrane and supports its ongoing cleaning during device operation.
In practice, the flow restrictor is responsible for forcing the proper water flow on the outlet side. This helps more effectively flush away contaminants accumulating on the membrane and carry them to the sewer. This matters both for filtration efficiency and for the service life of the membrane itself in the RO system.
Why is a flow restrictor important in an RO system?
In systems with an osmosis membrane, properly controlled wastewater discharge has a direct impact on the correct operation of the unit. The FR-550 is not just an installation accessory, but a component that helps maintain the proper operating conditions.
- forces the water flow needed to clean the membrane,
- supports flushing of the osmosis membrane during system operation,
- helps flush away accumulated contaminants,
- allows contaminants to be discharged to the sewer,
- affects the service life of the osmosis membrane,
- helps maintain the proper operation of the osmosis filter.
Installation and replacement
The FR-550 is connected using quick-connect fittings, which makes it easy to install in the system and later replace. The restrictor is mounted on the line carrying dirty water to the sewer, i.e. on the wastewater outlet in the reverse osmosis system.
When replacing the osmosis membrane with a new one, a new flow restrictor must also be installed. It should be fitted in place of the old, worn restrictor — on the line carrying dirty water to the sewer.
Regular replacement of the restrictor helps maintain proper membrane performance. In the case of heavily contaminated water, especially water containing a lot of calcium and iron, the restrictor should be replaced every few years. Such operation supports the correct functioning of the water treatment system and reduces the risk of deteriorated membrane operating conditions.
When is it worth replacing the FR-550 restrictor?
Replacement of the flow restrictor is recommended as part of proper reverse osmosis system maintenance. It is especially worth remembering when:
- the osmosis membrane is being replaced,
- the system operates on water with a high calcium content,
- there is an elevated amount of iron in the water,
- the restrictor has been in use for several years,
- you want to maintain proper membrane flushing in the water filter.
Technical specifications
| Model | FR-550 |
|---|---|
| Product type | Flow restrictor / restrictor |
| Intended use | Reverse osmosis systems |
| Installation location | Wastewater outlet / line carrying dirty water to the sewer |
| Connection type | Quick-connect fittings |
| Function | Forces the proper water flow, supports flushing and cleaning of the osmosis membrane, and discharge of contaminants to the sewer |
Product Details
FLOW550
964 Items
Data sheet
- Model
- FR-550
- Flow restrictor rating
- 550 ml/min
- Accessory type
- Flow restrictor
- Compatibility
- Universal RO systems
- Product type
- Flow restrictor
Questions
What is the FR-550 restrictor used for?
The FR-550 is used to limit and control the water flow at the wastewater outlet in a reverse osmosis system. This supports flushing of the osmosis membrane and helps discharge contaminants to the sewer.
Where is the FR-550 flow restrictor installed?
The component is installed on the line carrying dirty water to the sewer, i.e. on the wastewater outlet in the RO system.
Does the FR-550 fit reverse osmosis systems?
Yes, the FR-550 restrictor is intended specifically for use in reverse osmosis systems as a component working with the osmosis membrane.
Why does the restrictor affect the service life of the osmosis membrane?
A properly functioning restrictor forces the correct water flow, which supports membrane cleaning. This makes it easier to flush away contaminants and helps maintain proper membrane operating conditions for longer.
Does the restrictor also need to be replaced when replacing the membrane?
Yes, when replacing the osmosis membrane with a new one, a new flow restrictor should also be installed. It is fitted in place of the old, worn component.
How often should the FR-550 be replaced?
In the case of heavily contaminated water, especially with a high amount of calcium and iron, the restrictor should be replaced every few years. Regular replacement helps maintain proper membrane operation.
What type of connection does the FR-550 restrictor have?
The product is connected using quick-connect fittings, which simplifies installation and servicing in the water filtration system.
Does the restrictor help remove contaminants from the membrane?
Yes, the FR-550 supports the osmosis membrane flushing process. The forced water flow helps flush away accumulated contaminants and direct them to the sewer.
FR-550 restrictor (flow limiter) for reverse osmosis systems, mounted on the wastewater outlet. It enforces the proper water flow, which supports the flushing and cleaning of the osmotic membrane and helps to drain contaminants into the sewage system. Connection via quick couplings. When replacing the membrane, it is recommended to install a new restrictor.
